Parameter
|
10GEPON
|
XG-PON
|
|
Model
|
HT3541EVWU
|
HT3541GVWU
|
|
Chipset
|
CPU
|
EN7580GAT
|
|
WIFI
|
2.4G wifi MT7592N+5G wifi MT7612EN
|
|
VOIP
|
LE9643
|
|
BOSA driver
|
Semetch GN28L95
|
|
DDR3
|
512MByte
|
|
flash
|
256MByte
|
|
Product form
|
User interface
|
EPON/GPON+4GE+1USB+1POTS+WIFI 2.4G/5G
|
|
Network side interface
|
Interface type
|
10G EPON
|
XGPON
|
|
User side interface
|
LAN（GE）
|
4*10/100/1000M Base-T
|
4*10/100/1000M Base-T
|
|
PON
|
ONU ID authentication
|
SN/Password Identification&authentication
|
|
FEC
|
Support
|
|
DBA
|
Report t-cont queue status; accept OLT bandwidth
allocation; support 5 types of t-cont bandwidth
|
|
GPON Feature
|
T-CONT：8
GEM PORT：32
|
|
Optical link detection
|
Optical module working temperature, power supply
voltage, bias electrohydraulic, sending and receiving optical power, etc
|
|
Ethernet
|
MAC address
|
8K
|
|
VLAN
|
802.1q VLAN
|
4K(1~4094 VLAN ID settable)
|
|
VLAN funciton
|
VLAN division based on port, VLAN tagging,
unmarking, transparent transmission, filtering, VLAN trunk, 1:1 VLAN
conversion, COS mark
|
|
QoS
|
Stream classification
|
Message depth detection: Based on physical port,
source and destination MAC address, VLAN ID, user priority, Ethernet type,
source and destination IP address, IP protocol type, IP DSCP, source and
destination L4 protocol port upstream flow classification
|
|
Stream marking
|
flow classification based, the uplink service is
marked at the optimization level, and the priority mark is forced to be
modified
|
|
Dispatching queue
|
4網絡側/4用戶側隊列數4 network side /4 user side queues
|
|
scheduling algorithm
|
SP/WRR/SP+WRR
|
|
Discarding algorithm
|
Tail-Drop
|
|
Multicast
|
Multicast protpcol
|
IGMP Snooping
|
|
Multicast capacity
|
1K
|
|
Safety
|
PON data encryption
|
AES-128
|
|
MAC Quantitative restriction
|
1~256個/port
|
|
ACL
|
8
|
|
Network management
|
Network management mode
|
OMCI、OMCI+TR069、HTTP、Telnet
|
|
Network management content
|
Configuration management / fault management /
performance management / safety management
|
|
PON interface
|
Connector
|
SC/APC、SC/UPC
|
|
PON port number
|
1
|
1
|
|
PON port standard
|
CLASS B+
|
CLASS B+
|
|
PON wavelength
|
Tx 1310nm/Rx1577nm
|
Tx 1270nm/Rx 1577nm
|
|
Optical interface receiving rate
|
10Gbit
|
10Gbit
|
|
Optical interface transmission rate
|
1.25Gbit
|
2.488Gbit
|
|
Output optical power
|
Min +0.5dBm；Max+5dBm
|
Min +2dBm；Max +7dBm
|
|
Receiver sensitivity
|
Be better than -28.5dBm（Remark：TX on，ER-6dB，BER=10-3
|
|
Saturated optical power
|
Min -8dBm
|
|
Power
|
Input
|
AC 100 - 240V 50/60Hz
|
AC 100 - 240V 50/60Hz
|
|
Output
|
DC 12V 1.5A
|
DC 12V 1.5A
|
|
Physical
|
Size
|
229mmx110mmx48mm (L×W×H)
|
229mmx110mmx48mm (L×W×H)
|
|
Product silkprinting
|
Top cover
|
5 LEDs: Power, PON, LAN, WIFI, USB, POTS
|
|
Bottom interface
|
POTS, GE 4, GE 3, iTV, GE 1, reset, USB, DC 12V, PON
