HT308I-F/HT308GI-F在不影響性能的前提下,在任何環境下都能可靠、穩定、安靜地運行,快速、安全、輕松地部署家庭自動化網絡。
HT308I-F/HT308GI-F提供標準、VLAN和擴展三種工作模式。HT308I-F/HT308GI-F在標準工作模式下可作為普通千兆交換機使用。
HT308I-F/HT308GI-F的所有RJ45銅纜接口均支持10/100/1000Mbps自動協商,通過RJ45 6類、5類或5e類線纜進行最佳速度檢測。標準的自動MDI/MDI-X支持,可以檢測到任何以太網設備的連接類型,不需要特殊的直通或交叉電纜。
技術規格
Hardware Specifications |
||
Model |
HT308I-F |
HT308GI-F |
Network Connector |
8-Port 10/100BASE-T |
8-Port 10/100/1000BASE-T |
Switch Architecture |
Store and forward |
|
MAC Address Table |
2K MAC address table with auto learning function |
4K MAC address table with auto learning function |
Switch Fabric |
1Gbps / non-blocking |
16Gbps / non-blocking |
Switch Throughput |
1M |
11.9Mpps@64Bytes |
Jumbo Frame |
2048bytes |
9K bytes |
Flow Control |
IEEE 802.3x pause frame for full
duplex |
|
LED Indicators |
Power LED: Power |
|
ESD Protection |
4KV DC |
|
Connector |
DC power jack with 2.0mm central pole |
|
Power Requirements |
12V~48VDC |
|
Enclosure |
IP30 metal |
|
Dimensions (W x D x H) |
127mm× 107m m× 33mm |
|
Weight |
500g |
|
Installation |
Fixed wall mounting, magnetic wall mounting or DIN-rail mounting |
|
Standard Conformance |
||
Standard Compliance |
IEEE 802.3 Ethernet |
|
Regulatory Compliance |
FCC Part 15 Class A, CE |
|
Stability Testing |
IEC 60068-2-32 (Free fall) |
|
Environment |
||
Operating |
Temperature: -40 ~ 75 degrees C |
|
Storage |
Temperature: -40 ~85 degrees C |
|
Warranty |
5-year |
訂貨信息
HT308I-F |
Industrial 8-Port 10/100T flat type/Wall-mounted Gigabit Ethernet Switch |
HT308GI-F |
Industrial 8-Port 10/100/1000T flat type/Wall-mounted Gigabit Ethernet Switch |
